Description
Andrews - 212440 - Cam - BH Grind - Shovelhead
Features
- More mid-range and top-end power for street and drag bikes. These cams work with solid or hydraulic lifters, and the idle remains unaffected up to 6,000 rpm with stock valve springs
- Cams are computer designed and precision ground from alloy steel billets on Landis CNC cam grinders
- Made in the USA
- Must check coil bind, valve to valve clearance, and valve to piston clearance.
- On late '77 and later engines, the pitch diameter on the camshaft, pinion gear, and the breather valve gear was changed. These components are not interchangeable with earlier-style components unless replaced in set only. Late '77 and later gear sets are identified by a circular groove machined in the outer face of the cam gear.
Specs
| Exhaust Open Imperial | 52° |
| Riding Style | Street |
| Type | Gear |
| Intake Lift at TDC Imperial | 0.156'' |
| Intake Duration Imperial | 256° |
| Exhaust Lift Imperial | 0.450'' |
| Intake Close Imperial | 52° |
| Application | Exhaust |
| Units | Each |
| Exhaust Close Imperial | 24° |
| Exhaust Lift at TDC Imperial | 0.156'' |
| Grind | BH |
| Intake Open Imperial | 24° |
| Product Name | Cam |
| Intake Lift Imperial | 0.450'' |
| Application | Intake |
| Exhaust Duration Imperial | 256° |
Fitment
| 1980 | Harley-Davidson | 1200 Electra Glide FLH |
| 1979-1980 | Harley-Davidson | 1200 Fat Bob FXEF |
| 1978-1979 | Harley-Davidson | 1200 Low Rider FXS |
| 1978 | Harley-Davidson | 1200 Super Glide FX |
| 1978-1980 | Harley-Davidson | 1200 Super Glide FXE |
| 1983 | Harley-Davidson | Disc Glide FXDG |
| 1981-1982 | Harley-Davidson | Electra Glide Classic FLH |
| 1983 | Harley-Davidson | Electra Glide Classic FLHTC |
| 1978-1980 | Harley-Davidson | Electra Glide FL |
| 1978-1984 | Harley-Davidson | Electra Glide FLH |
| 1981 | Harley-Davidson | Electra Glide Heritage FLH |
| 1984 | Harley-Davidson | Electra Glide Special FLHX |
| 1980-1982 | Harley-Davidson | Electra Glide Sport FLHS |
| 1983 | Harley-Davidson | Electra Glide Standard FLHT |
| 1979-1981 | Harley-Davidson | Fat Bob FXEF |
| 1979-1982 | Harley-Davidson | Low Rider FXS |
| 1983-1984 | Harley-Davidson | Low Rider FXSB |
| 1983 | Harley-Davidson | Sport Glide FXRT |
| 1980-1982 | Harley-Davidson | Sturgis FXB |
| 1979-1984 | Harley-Davidson | Super Glide 80 FXE |
| 1982-1983 | Harley-Davidson | Super Glide II FXR |
| 1982-1983 | Harley-Davidson | Super Glide II FXRS |
| 1980-1983 | Harley-Davidson | Tour Glide Classic FLTC |
| 1980-1983 | Harley-Davidson | Tour Glide FLT |
| 1980-1984 | Harley-Davidson | Wide Glide FXWG |
