V-Twin - 35-0000 - Linkert Carburetor Float Assembly
Description
Linkert float arm assembly includes "unsinkable" linkert M float and a V-Twin one piece cast brass float arm,for smooth operation. Also includes the bolt and nut and pivot cap and pin set for mounts.
The float will not leak or swell and is impervious to modern fuel. It's the same weight as the original and uses the same settings. For use with all round-bowl series M Linkerts. *NOTE: For the float arm installation, the center prong of the float arm should have .003" of clearance, in order for the arm and needle to move freely. *NOTE: Follow instruction per factory service manual.
Fits:
- FL 1941-1965
- W 1936-1952
Additional Information
| UOM | 1 - KIT |
| Manufacturer | V-Twin |
| Origin | Imported |
| 2025 Catalog Pages | 710 |
| Replacement Items | 35-1872 - Replica Linkert Carburetor Float Lever 35-9063 - Linkert Carburetor Float Pivot Pin 35-9059 - Linkert Float Pivot Bolt and Nut Brass 35-0745 - Linkert Nitrophyl Carburetor Float |
