Brake Hardware
718 parts
Harley-Davidson brake hardware includes the bolts, fittings, pins, washers, clamps, switches and mounting components used throughout motorcycle braking systems. The range covers Harley-Davidson brake rotor hardware, caliper bolts, banjo bolts, brake line fittings, brake pad pins and brake lever hardware for a wide range of models. Products are available for hydraulic and mechanical brake systems, including older Harley-Davidson applications with drum brakes and backing plates. Model-specific hardware from Colony, V-Twin, Lyndall Brakes, Goodridge, Drag Specialties, Magnum Shielding and other manufacturers supports brake repairs, maintenance and component installation.
- Product
- Qty in Cart
- Quantity
- Price
- Subtotal
-
V-Twin - 23-0712 - Wheel Cylinder Swivel Fitting - Fits 1963-1972 Harley-Davidson FL, 1971-1972 FX
V-Twin Mfg
$35.41Brass swivel fitting attaches the brake hose to the back of the wheel cylinder backing plate. Fits:FL 1963-1972FX 1971-1972Additional Information OEM No.$35.41 -
V-Twin - 23-0709 - Brake Line Tee Chrome
Edart
$36.59V-Twin - 23-0709 - Brake Line Tee ChromeDescriptionTee has 4 ports. Three are inverted flares and one is 1/8" x 27 National Pipe Thread for stop lamp switch. Fits:GE 1951-1973FL 1958-1969Additional...$36.59 -
V-Twin - 23-0707 - Brake Line Tee Zinc plated
Edart
$25.43V-Twin - 23-0707 - Brake Line Tee Zinc platedDescriptionZinc plated rear brake line tee. Fits:FX 1980-1982FX 1977-1979FL 1972-1984Additional Information$25.43 -
V-Twin - 23-0704 - Steel Rear Brake Line Matte Chrome - Fits 1979-1984 Harley-Davidson FLH
V-Twin Mfg
MSRP: $70.39$67.49Matte chrome steel front section of rear brake line fits between the master cylinder and junction.NOTE: On 1936-1957 Big Twins, the brake arm faces rearward and in ...MSRP: $70.39$67.49 -
V-Twin - 23-0703 - Steel Rear Brake Line Chrome - Fits 1958-1969 Harley-Davidson FL
V-Twin Mfg
$61.66Steel rear middle section of the brake line fits from the junction toward the rear caliper.Order the rubber hose for final connection to rear wheel cylinder to caliper separately. ...$61.66 -
V-Twin - 23-0701 - Steel Rear Brake Line Chrome - Fits 1970-1978 Harley-Davidson FLH
V-Twin Mfg
$49.13Chrome steel front section of rear brake line fits between the master cylinder and junction.The end to end following the curve measures 22". *NOTE: Brake line will have oxidation under the nuts due...$49.13 -
V-Twin - 23-0700 - Steel Rear Brake Line Chrome - Fits 1958-1969 Harley-Davidson FLH, FL
V-Twin Mfg
$59.70Front section of rear brake line fits between the master cylinder and junction.*NOTE: Brake line will have oxidation under the nuts due to the plating process. Fits:FLH 1958-1969FL...$59.70 -
V-Twin - 23-0686 - Front Brake Hose Clamp
Edart
$27.92V-Twin - 23-0686 - Front Brake Hose ClampDescriptionClamp is 5/16" and fits under the triple tree to secure a stainless brake line. Mount hole is 1/4" x 20. Fits:Custom applicationAdditional...$27.92 -
V-Twin - 23-0675 - Front Brake Hose Clamp
Edart
MSRP: $23.86$22.31V-Twin - 23-0675 - Front Brake Hose ClampDescriptionClamp is 5/16" and fits under the triple tree to secure a stainless brake line. Mount hole is 1/4" x 20.Mount screws are included. Fits:Custom...MSRP: $23.86$22.31 -
V-Twin - 23-0666 - Mechanical Brake Cross Shaft Kit - Fits 1941-1957 Harley-Davidson FL, 1936-1952 EL
V-Twin Mfg
$96.16Mechanical brake cross shaft kit features bell cranks that are parkerized as original with correct nuts and lock tabs that are included. Fits:FL 1941-1957EL 1936-1952Additional Information$96.16 -
V-Twin - 23-0635 - Universal Straight Line Union 1/8 inch
Edart
$24.83V-Twin - 23-0635 - Universal Straight Line Union 1/8 inch Description Includes bracket and is 1/8" national pipe thread. Fits: Custom application Additional Information$24.83 -
V-Twin - 23-0615 - Banjo Bolt Washers 12mm
Edart
MSRP: $7.86$7.78V-Twin - 23-0615 - Banjo Bolt Washers 12mmDescriptionWashers are alloy type and for use with lines with a 12mm hole size. These washers are without the o-ring. Fits:FXST 1984-2010XL 1984-2003FXD...MSRP: $7.86$7.78 -
V-Twin - 23-0614 - 12 Hex Banjo Bolt Kit 12mm
Edart
$15.72V-Twin - 23-0614 - 12 Hex Banjo Bolt Kit 12mmDescriptionBolt kit is for use with front or rear universal or stock lines with 12mm hole size. Bolt is 7/16-24 with a 12 hex head. Fits:FXST 1984-2010XL...$15.72 -
V-Twin - 23-0613 - Banjo Bolt Washers 10mm
Edart
MSRP: $12.56$12.43V-Twin - 23-0613 - Banjo Bolt Washers 10mmDescriptionWashers are alloy type and for use with lines with a 10mm hole size. These washers are without the o-ring. Fits:FXD 1994-2010FLT 1982-2009XL...MSRP: $12.56$12.43 -
V-Twin - 23-0603 - Hydraulic Brake Shoe Retainer Clip Set
Edart
$27.71V-Twin - 23-0603 - Hydraulic Brake Shoe Retainer Clip SetDescriptionHydraulic brake shoe retainer clip set is black oxide.Sold as a pair. Fits:FX 1971-1972FLH 1958-1972Additional Information$27.71 -
V-Twin - 23-0601 - Rear Hose Nut and Washer Kit
Edart
$37.33V-Twin - 23-0601 - Rear Hose Nut and Washer KitDescriptionKit includes a hex nut and lock washer for a rear brake hose at the frame mounting point. Fits:FX 1971-1972FL 1958-1972Additional Information$37.33 -
V-Twin - 23-0571 - Brake Line Tee Chrome
Edart
$35.81V-Twin - 23-0571 - Brake Line Tee ChromeDescriptionChrome steel tee with a 5/16" mounting hole with a center hole that is 1/8"-27 national pipe thread. Side tubes are 3/8"-24 fine thread. Tee is 1/2"...$35.81 -
V-Twin - 23-0570 - Chrome Brake Hose Tee
Edart
$32.07V-Twin - 23-0570 - Chrome Brake Hose TeeDescriptionChrome steel tee with a 5/16" mounting hole has an inverted flare center hole that is 3/8"-24 Unified National Fine. Side tubes are 3/8" - 24...$32.07 -
V-Twin - 23-0519 - Front Brake Shoe Cam - Fits 1971-1972 Harley-Davidson FX, 1964-1972 XL
V-Twin Mfg
$33.53Brake shoe cam. Fits:FX 1971-1972XL 1964-1972Additional Information OEM No.44264-64 UOM1 - E$33.53 -
V-Twin - 23-0517 - Chrome Brake Hose Fitting
V-Twin Mfg
$15.48V-Twin - 23-0517 - Chrome Brake Hose FittingDescriptionFront master cylinder brake hose fitting converts 10mm late threads to 1/8" NPT inverted flare, early thread hose type, straight.Fitting...$15.48 -
V-Twin - 23-0464 - Mechanical Brake Rod Clevis Pin
Edart
$27.24V-Twin - 23-0464 - Mechanical Brake Rod Clevis PinDescriptionMechanical brake clevis parkerized pin includes washer and cotter pin. Fits:UL 1937-1948EL 1936-1940FL 1941-1957Additional Information$27.24 -
V-Twin - 23-0443 - Front Mechanical Brake Rod Clevis
Edart
$29.58V-Twin - 23-0443 - Front Mechanical Brake Rod ClevisDescriptionParkerized front mechanical brake rod short clevis. Fits:UL 1937-1948EL 1936-1940FL 1941-1957Additional Information$29.58 -
V-Twin - 23-0442 - Rear Hydraulic Brake Drum Race
Edart
MSRP: $71.55$70.83V-Twin - 23-0442 - Rear Hydraulic Brake Drum RaceDescriptionRace for a rear hydraulic brake drum. Fits:FL 1967-1972FX 1971-1972FLH 1967-1972Additional InformationMSRP: $71.55$70.83 -
V-Twin - 23-0441 - Mechanical Brake Drum Dowel Pin Set Rear
Edart
$36.59V-Twin - 23-0441 - Mechanical Brake Drum Dowel Pin Set RearDescriptionDowel pin set for mechanical rear brake drum. Fits:UL 1937-1948 Front or RearEL 1936-1940 Front or RearFL 1941-1972 Front or...$36.59 -
V-Twin - 23-0424 - Front Mechanical Brake Rod Clevis
Edart
MSRP: $18.30$18.12V-Twin - 23-0424 - Front Mechanical Brake Rod ClevisDescriptionChrome mechanical brake rod short clevis. Fits:UL 1937-1948EL 1936-1940FL 1941-1957Additional InformationMSRP: $18.30$18.12 -
V-Twin - 23-0420 - Replica Rear Brake Shoe Backing Plate Black
Edart
$136.77V-Twin - 23-0420 - Replica Rear Brake Shoe Backing Plate BlackDescriptionReplica black backing plate for the rear brake shoe.NOTE: On 1936-1957 Big Twins, the brake arm faces rearward and in. Fits:UL...$136.77 -
V-Twin - 23-0419 - Mechanical Rear Brake Crossover Shaft - Fits 1931-1936 Harley-Davidson VL, 1936-1940 EL, 1941-1957 FL, 1938-1948 UL
V-Twin Mfg
$54.91Rear mechanical brake crossover shaft is original style with 47/64" diameter. Fits:VL 1931-1936EL 1936-1940FL 1941-1957UL 1938-1948Additional Information$54.91 -
V-Twin - 23-0418 - Parkerized Rear Brake Pivot and Cup Kit - Fits 1937-1948 Harley-Davidson UL, 1936-1940 EL, 1941-1957 FL
V-Twin Mfg
$37.69Kit includes one outside and one inside pivot cup, and one pivot stud for mechanical brake. Fits:UL 1937-1948EL 1936-1940FL 1941-1957Additional Information$37.69 -
V-Twin - 23-0417 - Rear Brake Cam Raw - Fits 1937-1948 Harley-Davidson UL, 1936-1940 EL, 1941-1957 FL
V-Twin Mfg
$36.59Raw rear mechanical brake cam for rigid brakes.NOTE: On 1936-1957 Big Twins, the brake arm faces rearward and in. Fits:UL 1937-1948EL 1936-1940FL 1941-1957Additional Information$36.59 -
V-Twin - 23-0416 - Rear Brake Backing Lock Plate Black - Fits 1941-1957 Harley-Davidson FL (rear), 1941-1957 G (front), 1936-1952 EL (rear), 1936-1948 EL (front), 1941-1948 FL (front)
V-Twin Mfg
$16.14Black backing lock plate for rear mechanical brake. Fits:FL 1941-1957 rearG 1941-1957 frontEL 1936-1952 rearEL 1936-1948 frontFL 1941-1948 frontAdditional Information$16.14 -
V-Twin - 23-0415 - Rear Brake Backing Plate Chrome
Edart
$148.72V-Twin - 23-0415 - Rear Brake Backing Plate ChromeDescriptionChrome backing plate for rear mechanical brake.NOTE: On 1936-1957 Big Twins, the brake arm faces rearward and in. Fits:UL 1937-1948EL...$148.72 -
V-Twin - 23-0412 - Rear Backing Plate Pivot Stud Nut
Colony Machine
MSRP: $13.54$13.40V-Twin - 23-0412 - Rear Backing Plate Pivot Stud NutDescriptionRear backing plate pivot stud nut for mechanical brake. Fits:K 1952-1956XL 1957-1972Additional InformationMSRP: $13.54$13.40 -
V-Twin - 23-0411 - Rear Mechanical Brake Locating Block Zinc - Fits 1952-1956 Harley-Davidson K, 1957-1972 XL
V-Twin Mfg
$19.66Zinc locating block for the rear mechanical brake. Fits:K 1952-1956XL 1957-1972Additional Information OEM No.41730-52$19.66 -
V-Twin - 23-0328 - Hummer Brake Rod - Fits 1966 Harley-Davidson Model 125, 1963-1965 Hummer
V-Twin Mfg
$44.42Zinc Hummer brake rod. Fits:Model 125 1966-1966Hummer 1963-1965Additional Information OEM No.42256-63$44.42 -
V-Twin - 23-0147 - Vibration Shims for Rear Brake Pads
Edart
MSRP: $11.14$11.02V-Twin - 23-0147 - Vibration Shims for Rear Brake PadsDescriptionVibration shims for rear pads to dampen pad rattle. Fits:FXST 2000-UP Front or RearFLST 2000-UP Front or RearXL 2000-2003 Rear...MSRP: $11.14$11.02 -
V-Twin - 23-0128 - Front Backing Plate Pivot Stud - Fits 1937-1948 Harley-Davidson UL, EL, 1941-1957 G, 1941-1948 FL
V-Twin Mfg
$24.18Spring fork front brake backing plate pivot stud with lock plate. Fits:UL 1937-1948EL 1937-1948G 1941-1957FL 1941-1948Additional Information$24.18 -
V-Twin - 23-0127 - Rear Brake Backing Plate Pivot Stud Kit - Fits 1952-1956 Harley-Davidson K, 1957-1972 XL
V-Twin Mfg
$27.92A 3 piece set includes the locating block, pivot stud, and chrome nut.For use with a drum type mechanical brake. Order spacers separately. Fits:K 1952-1956XL 1957-1972Additional Information$27.92 -
V-Twin - 23-0080 - Brake Fitting Kit
Edart
$47.78V-Twin - 23-0080 - Brake Fitting KitDescriptionBrake fitting kit includes a brass fitting, bolt and copper sealing washer set. Fits:FL 1963-1972Additional Information$47.78 -
V-Twin - 23-0068 - Mechanical Brake Pivot Kit Chrome
Edart
$50.39V-Twin - 23-0068 - Mechanical Brake Pivot Kit ChromeDescriptionMechanical brake pivot kit with serrated lock plate and nut, is for cast shoe set applications.Ten piece kit features chrome finish on...$50.39 -
V-Twin - 23-0066 - Mechanical Brake Pivot Kit Parkerized
Edart
$50.39V-Twin - 23-0066 - Mechanical Brake Pivot Kit ParkerizedDescriptionMechanical brake pivot kit with serrated lock plate and nut.Ten piece kit features parkerized finish on all components except rear...$50.39
Harley-Davidson Brake Hardware – Rotor Bolts, Caliper Hardware & Brake Fittings
Harley-Davidson brake hardware consists of the smaller components that secure, connect, adjust and support the motorcycle's braking system. This category includes Harley-Davidson brake rotor bolts, caliper mounting bolts, brake pad pins, banjo bolts, washers, clevis pins, pivot hardware and brake lever components. Hydraulic brake systems also require specialized Harley-Davidson brake line fittings, banjo fittings, junction blocks, brake hose adapters and brake light switches. The product range covers both replacement hardware for original brake systems and components used with aftermarket calipers, rotors, brake lines and other braking equipment.
The range includes hardware for front and rear brake applications across Sportster, Dyna, Softail, Touring, Big Twin, FX, FL and other Harley-Davidson models. Products include Harley-Davidson caliper bolts, rotor-to-hub bolt kits, floating rotor mounting hardware, rear rotor bolts with nuts, brake hose banjo bolts, hydraulic brake switches, pad pins, brake line tees and universal brake fittings. Older applications are also represented through mechanical brake components such as backing plate hardware, brake drum bolts, pivot studs, brake rod clevis pins, cam components, cable adjusters and related fasteners. This broad selection makes the category relevant to both modern hydraulic disc-brake systems and earlier Harley-Davidson mechanical braking configurations.
Fitment is important when selecting Harley-Davidson brake hardware, since thread size, bolt length, mounting style, rotor design, caliper configuration, brake line connection and model year can vary significantly. Rotor bolts and caliper fasteners must match the applicable mounting arrangement, while banjo bolts, washers, fittings and brake line components need to correspond with the hose and hydraulic system being serviced. Model-specific hardware kits can simplify replacement of original fasteners, while universal fittings and adapters provide additional options for custom brake lines and aftermarket brake systems. Correctly matched Harley-Davidson brake hardware kits, mounting hardware and hydraulic fittings help maintain proper component fitment during brake service and installation.
